Phoenix QUINT-UPS/ 24DC/ 24DC/ 5/1.3AH-Uninterruptible power supply 2320254, uninterruptible power supply with IQ Technology and built-in battery, for DIN rail installation, input: 24V DC, output: 24V DC/5 A, battery: leaded AGM 1.2 Ah, including installed universal DIN rail adapter UTA 107/30
DC operation
input voltage
24V DC
Input Voltage Range
18V DC ... 30V DC
DC input voltage range
18V DC ... 30V DC
Supply Voltage
DC
buffer time
50 min (1 A)
5 min (5 A)
power consumption
9.3 A (24V DC)
9.7 mA
1.7 A
7 A
Fixed Backup Threshold
≤ 22.6V DC
efficiency
> 97.1 % (mains operation, with charging power storage device)
97.31 percent
Rated output voltage
24V DC
Output Voltage Range
18V DC ... 30V DC
Rated output current (IN)
5 A (0°C ... 40 °C)
Output Current Limit
> 7.5 A (battery operated)
bridge time
360 s
Attenuation
60°C ... 70°C (2.5 %/K)
output power
120W
power consumption
2.5W (main line operation)
2.7W (main line operation)
1.9W (main line operation)
3.3W (battery operated)
3.3W (battery operated)
4.1W (battery operated)
output fuse
1x 15 A
Parallel
2
Concatenation
No
mains power supply
Rated output voltage
24V DC
Output Voltage Range
18V DC ... 30V DC (UOUT= UIN- 0,1V DC)
Rated output current (IN)
5 A (0°C ... 40 °C)
POWER BOOST (IBoost)
7.5 A (0°C ... 40 °C)
selective fusing (ISFB)
30 A (0°C ... 40 °C)
cycle
12 ms (SFB technology)
battery operation
Rated output voltage
24V DC
Output Voltage Range
19.2V DC ... 27.6V DC (UOUT= UBAT- 0,5V DC)
Rated output current (IN)
5 A (0°C ... 40 °C)
POWER BOOST (IBoost)
7.5 A (0°C ... 40 °C)
selective fusing (ISFB)
32.5 A (0°C ... 40 °C)
cycle
15 ms (SFB technology)
signal: alarm
Output Description
relay
output voltage
≤ 30V AC/DC
Continuous load current
≤ 100 mA
signal: battery charging
Output Description
relay
output voltage
≤ 30V AC/DC
Continuous load current
≤ 100 mA
signal: battery mode
Output Description
relay
output voltage
≤ 30V AC/DC
Continuous load current
≤ 100 mA
signal
Continuous load current
≤ 200 mA
2320267
