Phoenix STEP-PS/ 1AC/ 5DC/2-power supply 2320513, primary switch mode STEP POWER power supply, support DIN rail installation and direct installation, input: single phase, output: 5V DC/2 A
| AC operation | |
| Rated input voltage range | 100V AC ... 240V AC |
| Input Voltage Range | 85V AC ... 264V AC |
| 95V DC ... 250V DC | |
| AC input voltage range | 85V AC ... 264V AC |
| DC input voltage range | 95V DC ... 250V DC |
| Supply Voltage | AC/DC |
| Impulse current | < 15 A |
| impulse current integral (I2t) | < 0.1 A2s |
| AC frequency range | 45Hz ... 65Hz |
| DC frequency range | 0Hz |
| grid buffer time | Typical 25 ms (120V AC) |
| Typical 110 ms (230V AC) | |
| power consumption | 0.2 A (120V AC) |
| 0.13 A (230V AC) | |
| Rated power consumption | 28.9 VA |
| power factor (cos phi) | 0.44 |
| Typical Response Time | < 0.5 s |
| input fuse | 1.25 A (slow fuse, internal) |
| Allowed DC Spare Fuses | DC: Connect a suitable fuse |
| recommend use | 6 A ... 16 A (AC: characteristics B, C, D, K) |
| efficiency | > 81% (230V AC and rated) |
| output characteristics | U/ I |
| Rated output voltage | 5V DC |
| Output current Imax | 3.7 A |
| Rated output current (IN) | 2 A (-25°C ... 40°C constant) |
| 2.2 A (-25°C ... 55 °C) | |
| Attenuation | 55°C ... 70°C (2.5 %/K) |
| output | < 10V DC |
| residual wave | < 50 mVSS |
| output power | 10W |
| maximum no-load power consumption | < 0.4W |
| Maximum rated load power loss | < 2.6W |
| and connect | Yes, for redundancy and increased capacity |
| Concatenation | is |
| Input | |
| Connection Mode | screw connection |
| Minimum cross section of rigid conductor | 0.2 mm² |
| Maximum cross section of rigid conductor | 2.5 mm² |
| flexible lead | 0.2 mm² |
| Flexible lead maximum cross section | 2.5 mm² |
| Minimum Wire Cross Section AWG | 24 |
| Maximum conductor cross section AWG | 12 |
| stripping length | 6.5mm |
| thread | M3 |
| Minimum tightening torque | 0.5 Nm |
| Maximum tightening torque | 0.6 Nm |
| Output | |
| Connection Mode | screw connection |
| Minimum cross section of rigid conductor | 0.2 mm² |
| Maximum cross section of rigid conductor | 2.5 mm² |
| flexible lead | 0.2 mm² |
| Flexible lead maximum cross section | 2.5 mm² |
| Minimum Wire Cross Section AWG | 24 |
| Maximum conductor cross section AWG | 12 |
| stripping length | 6.5mm |
| thread | M3 |
| Minimum tightening torque | 0.5 Nm |
| Maximum tightening torque | 0.6 Nm |
| Signal Type | LED |
| Operating voltage display | Green LED |
| signal output: LED status display | |
| Status Display | DC OK LED green |
| Notes on Status Display | UOUT> 4V: LED flashing |
| color | Green |
| Notes on Status Display | LED on |
