Phoenix VS-PPC-C1-RJ45-MNNA-PG9-4Q5-B-RJ45 connector 1405141,RJ45 connector, protection level: IP65/IP67, number of digits: 4, CAT5 (IEC 11801:2002), identification material: metal, wiring method: IDC quick connection, wiring capacity: AWG 26- 22, Cable outlet: straight head, color: silver, PROFINET
| Product Type |
data connector (cable side) |
| type |
RJ45 |
| Sensor Type |
PROFINET |
| Bits |
4 |
| Connection Chart |
RJ45 8(4) |
| Outlet No. |
1 |
| Shielding |
have |
| cable outlet |
straight head |
| insulation characteristics |
| Overvoltage Category |
I |
| pollution level |
2 |
| Rated voltage (III/3) |
72V (DC) |
| Rated current |
1.75 A |
| Rated voltage UN |
48V |
| contact resistance |
0.001 Ω (conductor-IDC) |
| 0.005 Ω (stranded wire-IDC) |
| transmission medium |
copper cable |
| transmission characteristics (category) |
CAT5 |
| transmission rate |
100 Mbps |
| connection technology |
| Connection Mode |
IDC Quick Connect |
| Connectable Wire Cross Section AWG |
26 ... 22 (rigid) |
| 26 ... 22 (flexible) |
| Wire Cross Section |
0.13 mm² ... 0.32 mm² (rigid) |
| 0.14 mm² ... 0.36 mm² (flexible) |
| width |
22mm |
| height |
30mm |
| length |
72mm |
| color |
silver |
| Identification Materials |
metal |
| flame retardant rating to UL 94 |
V0 |
| O-ring sealing material |
NBR |
| Cable sealing material |
TPE |
| sealing material |
NBR |
| Shell Material |
metal |
| Shell surface material |
nickel plating |
| Cable sealing material |
TPE |
| Contact Material |
CuSn |
| Material Contact Surface |
Au/Ni |
| Contact Carrier Material |
PC |
| O-ring material |
NBR |
| screw connection material |
CuZn |
| Cable outer diameter |
5mm ... 8mm |
| Cable outer diameter |
5mm ... 8mm |
| Mechanical parameters |
| Insertion/unplugging cycle |
≥ 500 |
| environmental conditions |
| protection level |
IP65/IP67 |
| ambient temperature (operation) |
-40°C ... 70°C |
| ambient temperature (storage/transport) |
-40°C ... 80°C |
| ambient temperature (assembly) |
-5°C ... 45°C |
| Standards/Specifications |
IEC PAS 61076-3-117 |
