Phoenix SACC-V-3CON-M16/A-1L-S-valve connector 1544714, valve connector, universal, 3-position, valve connector A, screw connection, cable seal M16, cable outer diameter 5mm ... 10mm
| Product Type | Valve Connector |
| Sensor Type | General |
| Bits | 3 |
| Outlet No. | 1 |
| Shielding | None |
| Pg screw connection | M16 |
| insulation characteristics | |
| Overvoltage Category | II |
| pollution level | 3 |
| flame retardant rating, according to UL 94 | HB |
| sealing material | NBR |
| material shell solenoid valve plug | PA |
| Contact Material | CuSn |
| ferrule material of solenoid valve plug | PBT |
| Contact Surface Material | Ag |
| External dimensions | |
| outside diameter | 5mm ... 10mm |
| contact resistance | ≤ 4 mΩ |
| insulation resistance | > 2 GΩ |
| Rated voltage UN | 24V AC |
| 24V DC | |
| Rated current IN | 4 A |
| protection circuit | surge protection; zener diode |
| Mechanical parameters | |
| Insertion/unplugging cycle | 50 (valve plug) |
| Status Display | LED (yellow) |
| Status Display | have |
| Connection Mode | screw connection |
| Wire Cross Section | 0.34 mm² ... 2.5 mm² |
| CONNECTED WIRE CROSS SECTION AWG | 22 ... 13 |
| connection 1 | |
| Socket Design | Valve Connector |
| socket thread type | A |
| environmental conditions | |
| protection level | IP65 |
| ambient temperature (operation) | -25°C ... 60°C (valve connector) |
| Valve Plug | |
| Standard Identification | Valve Plug |
| Standards/Specifications | EN 175301-803 |
Phoenix SACC-V-3CON-M16/A-1L-S-Valve Connector 1544714
