Phoenix IB IL 120 DI 1-PAC-digital quantity module 2861917,Inline, digital quantity input module, digital input: 1,120V AC, connection technology: 3 wires, local bus transmission rate: 500 kBit/s, protection level: IP20, including Inline connector and identification area
width
12.2mm
height
119.8mm
depth
71.5mm
Description
Application Description
Application Description
for industrial applications only
Interface
Inline Local Bus
interfaces
2
Connection Mode
Inline data span block
transmission speed
500 kBit/s
System Properties
Module
ID Code (dec.)
190
Hex ID Encoding
BE
Length Encoding (Hexadecimal)
C2
length encoding (decimal)
194
Process Data Channel
2.
Input Address Area
2.
Output Address Area
0 Byte
Register Length
2.
the required parameter data
1 Byte
4 Byte
input data
digital quantity:
Enter Name
Digital Input
Input Description
IEC 61131-2 Type 1
Input Quantity
1
Connection Mode
pull-back spring connection
connection system
3 lines
input voltage
120V AC
input voltage range, "0" signal
0V AC ... 40V AC
input voltage range, "1" signal
77V AC ... 135V AC
Rated input voltage UIN
120V AC
Rated input current UIN
8.1 mA (rated voltage)
sensor current per channel
Max. 500 mA
Product Properties
Product Type
I/O components
product series
Inline
type
Module
Scope of supply
includes Inline connector and identification area
Channels
1
Electrical characteristics
rated conditions
1.2W
potential: communication power supply (UL )
supply voltage
7.5V DC (across the power supply)
current consumption
max. 30 mA
potential: I/O power supply
supply voltage
120V AC (via power crossover)
current consumption
0.25 A
power supply: electronic module
supply voltage
120V AC
Supply Voltage Range
108V AC ... 135V AC
