Phoenix IB IL AI/TEMP 4 RTD-PAC-analog module 2897952,Inline, analog input module, 0V ... 10V, local bus transmission rate: 500 kBit/s, protection level: IP20, including Inline connector and marker strip
width
12.2mm
height
140.5mm
depth
71.5mm
Application Description
Application Description
for industrial applications only
Use Restrictions
EMC Description
EMC: Class A products, see the manufacturer's declaration in the download area
Inline Local Bus
Connection Mode
Inline data span block
transmission speed
500 kBit/s
transmission principle
copper cable
Module
ID Code (dec.)
95
Hex ID Encoding
5F
Length Encoding (Hexadecimal)
02
length encoding (decimal)
02
Process Data Channel
32 bits
Input Address Area
4 Byte
Output Address Area
4 Byte
Register Length
32 bits
the required parameter data
1 Byte
5 Byte
simulation:
voltage input signal
0V ... 10V
data format
IB IL,IB ST, standardized display, compatible with S7
filtering
no or average based on 8 or 32 measurements
cut-off frequency (3dB)
6.6Hz
Measurement value resolution
16 bits (15 bits + sign bit)
simulation
input filter time
150 ms
1200 ms
4800 ms (settable)
Linear resistance measuring range
0 Ω ... 3 kΩ
0 Ω ... 300 kΩ
Product Type
I/O components
Product Series
Inline
type
Module
Scope of supply
includes Inline connector and marker strip
insulation characteristics
Overvoltage Category
II (IEC 60664-1,EN 60664-1)
pollution level
2 (IEC 60664-1,EN 60664-1)
2861276
