Phoenix TRIO3-PS/3AC/24DC/40-power supply 1159045, primary switching power supply, TRIO POWER, in-line connection, DIN rail installation, input: 3 phases, output: 24V DC/40 A, adjustable range 24V DC ... 28V DC
AC operation
Power System Configuration
star network (TN,TT,IT (PE))
Rated input voltage range
3x 400V AC ... 500V AC
Input Voltage Range
3x 400V AC ... 500V AC -20 % ... +10%
2x 400V AC ... 500V AC ±10%
National Grid Typical Voltage
3x 400V AC
3x 480V AC
Supply Voltage
AC
Impulse current
< 21 A (25 °C)
impulse current integral (I2t)
< 0.77 A2s
frequency range (fN)
50Hz ... 60Hz ± 10%
grid buffer time
Typical 21 ms (3x 400V AC)
Typical 21 ms (3x 480V AC)
power consumption
3x 1.5 A (3x 400V AC)
3x 1.2 A (3x 500V AC)
2x 2.6 A (2x 400V AC)
2x 2.1 A (2x 500V AC)
protection circuit
transient protection; varistor
power factor (cos phi)
0.94 (3x 480V AC)
Device Power Fuse
6.3 A built-in (device protection)
recommend use
3x 6 A ... 16 A (characteristics B, C, D, K or similar)
PE discharge current
< 3.5 mA
efficiency
Typical 95.4 % (3x 400V AC)
Typical 95.8 % (3x 480V AC)
Rated output voltage
24V DC
output voltage (USet) setting range
24V DC ... 28V DC (> 24V DC, stable capacity limit)
Rated output current (IN)
40 A
Dynamic Boost (IDyn.Boost)
max. 60 A (5 s)
Short-circuit protection
is
Anti-aircraft turn
is
Attenuation
60°C ... 70°C
amplitude factor
Typical 1.54 (3x 400V AC)
Typical 1,53 (3x 480V AC)
output power (PN)
960W
output power (Pdynamic margin)
Max. 1440W (5 s)
Concurrent
, the use of diodes allows for increased power and increased redundancy
Concatenation
Yes, for higher output voltages (in compliance with SELV limits)
