Phoenix PSR-PC32-2NO-1NC-24-230UC-SP-coupling relay 2700582, coupling relay, can meet various SIL 3 application requirements, can connect digital signal to I/O,24V ... 230V wide range voltage input, 2 normally open safety contact outputs (1 channel up to 60V,1 channel up to 250V),1 feedback loop, suitable for applications with closed safety state, pluggable in-type terminal
| Product Type | coupling relay |
| Product Series | PSRmini |
| Application | Safety Shutdown |
| high requirements | |
| low requirements | |
| Ex | |
| control | Single and Dual Channel |
| Relay Model | Electromechanical relay with mechanical interlocking contacts according to IEC/EN 61810-3 |
| insulation characteristics | |
| Overvoltage Level | III |
| pollution level | 2 |
| Typical Response Time | < 100 ms (when controlled by A1, there is us) |
| Typical release time | < 200 ms (when controlled by A1, there is us) |
| Recovery Time | < 500 ms |
| rated conditions | 5.7W (in US= 42V AC, IL² = 72 A²) |
| Rated operating mode | 100% Eligible |
| Rated insulation voltage | 250V AC |
| rated overvoltage/insulation | 4 kV basic insulation between all current paths and enclosure |
| Safety isolation, 2.5 kV reinforced insulation between (93/94) and (31/32, 24V/GND) | |
| 6 kV reinforced insulation: Between (A1/A2), (13/14) and (31/32, 24V/GND) between (A1/A2) and (93/94) Between (13/14) and (93/94) |
|
| Power | |
| Name | A1/A2 |
| Rated control circuit supply voltage US | 24V AC/DC ... 230V AC/DC -15 % ... +10% |
| Rated control supply current IS | 75 mA (24V DC) |
| 34 mA (48V DC) | |
| 97 mA (42V AC) | |
| 28 mA (120V AC) | |
| 16 mA (230V AC) | |
| US | 1.8W (DC applicable) |
| 2.1W (AC) | |
| apparent power | Typical 4.1 VA |
| Impulse current | typical 16 A (& Delta;t < 100 & micro;s Us) |
| < 5 mA (24V/GND at combined terminal (UD)) | |
| filter time | 10 ms (e. g. Usvoltage dip, 24V DC, A1) |
| max. 1.5 ms (A1-A2; test pulse width; 24V DC) | |
| 7.5 ms (at A1-A2; test pulse rate; 24V DC) | |
| test pulse rate = 5 x test pulse width | |
| protection circuit | surge protection; 275V rheostat |
| Power | |
| Name | 24V/GND |
| Diagnostic supply voltage UD | 24V DC -15 % / +10% |
| UDinput current | < 5 mA (24V/GND at combined terminal (UD)) |
| protection circuit | surge protection; 33V suppressor diode |
| polarity protection | |
