Phoenix GW PL PA/MODBUS-Transport Protocol Converter 2316364,Modbus/RTU Protocol to PROFIBUS PA Protocol Converter
| Product Type | Interface Interface Converter |
| insulation characteristics | |
| Overvoltage Category | II |
| pollution level | 2 |
| power supply | |
| Supply Voltage Range | 18V DC ... 30V DC |
| Rated supply voltage | 24V DC |
| Maximum current consumption | 34 mA |
| power supply | |
| Connection Mode | plug-in COMBICON screw terminal block |
| Flexible Wire Cross Section | 0.20 mm² ... 2.50 mm² |
| Hard Wire Cross Section | 0.20 mm² ... 2.50 mm² |
| Connectable Guide Cross Section AWG | 24 ... 12 |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| signal | Modbus |
| Data for: PROFIBUS PA | |
| Data Rate | 31.25 kbps |
| connection quantity | 1 |
| Connection Mode | COMBICON |
| Channels | 1 |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| connection system | screw connection |
| terminal resistance | switchable |
| Flexible lead maximum cross section | 2.5 mm² |
| flexible lead | 0.2 mm² |
| Maximum cross section of rigid conductor | 2.5 mm² |
| Minimum cross section of rigid conductor | 0.2 mm² |
| Maximum conductor cross section AWG | 12 |
| Minimum Wire Cross Section AWG | 24 |
| Supported Protocols | Modbus/RTU,PROFIBUS PA |
| data: Modbus/RTU | |
| Data Rate | 115.2 kbps |
| connection quantity | 2 |
| Connection Mode | COMBICON |
| Channels | 4 (Modbus/RTU device) |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| connection system | screw connection |
| terminal resistance | switchable |
| Flexible lead maximum cross section | 2.5 mm² |
| flexible lead | 0.2 mm² |
| Maximum cross section of rigid conductor | 2.5 mm² |
| Minimum cross section of rigid conductor | 0.02 mm² |
| Maximum conductor cross section AWG | 12 |
| Minimum Wire Cross Section AWG | 24 |
Phoenix GW PL PA/MODBUS-Transport Protocol Converter 2316364
