Phoenix RFC 480S PN 4TX-safety controller 2404577, remote field controller with 4 x 10/100/1000 Ethernet, PROFINET controller integrated PROFIsafe safety controller, PROFINET device, IP20 protection level, plug-in Parameter memory
| Product Type |
controller |
| product series |
Remote Field Controller |
| type |
Stand-alone |
| insulation characteristics |
| protection level |
III (IEC 61140,EN 61140,VDE 0140-1) |
| Display |
| Diagnostic Display |
is |
| Processor |
Intel®Core™ i5-6300U, 2x 2.4 GHz (Dual-Core) |
| Arm®Cortex®-A 9 800 MHz (Safe) |
| Arm®Cortex®-A 8 600 MHz (Safe) |
| reserved data storage |
2 Mbyte |
| IEC 61131 runtime system |
| Program Memory |
Typical 16 Mbyte |
| data storage system |
32 Mbyte |
| control tasks |
16 |
| PROFINET |
| Device Features |
PROFINET controller, PROFINET equipment |
| Update Rate |
minimum 1 ms |
|
maximum 256 |
| Function |
| Diagnostic Display |
is |
| redundancy function |
No |
| safety function |
is |
| Function |
| Supported Programming Languages |
Instruction List (IL) |
| Symbolic Flowchart (SFC) |
| Ladder Diagram (LD) |
| Function Block Diagram (FBD) |
| Structure Text (ST) |
| System Requirements |
| Engineering Design Tools |
PC Worx |
| Diagnostic Tools |
DIAG, version 2.00 or higher |
| Application Interface |
Device Driver Interface via TCP/IP Socket |
| power consumption |
Typical 25W (without fan module) |
| maximum 35W (with fan module) |
| rated conditions |
Typical 24W (without fan module) |
| Typical 24W (without fan module) |
| Power |
| supply voltage |
24V DC |
| Supply Voltage Range |
19.2V DC ... 30V DC (with ripple) |
| Connect power supply |
screw terminal block, pluggable |
| Typical current consumption |
1 A |
| Real Time Clock |
| Real Time Clock |
integrated (with battery) |
| COMBICON connector |
| Hard Wire Cross Section |
0.2 mm² ... 2.5 mm² |
| Flexible Wire Cross Section |
0.2 mm² ... 2.5 mm² |
| Attachable Guide Cross Section AWG |
24 ... 12 |
| Web Server |
No |
| USB |
| interfaces |
1 |
| Connection Mode |
Type A USB, pin connector |
| Ethernet |
| bus system |
RJ45 |
| interfaces |
4 |
| Connection Mode |
RJ45 female connector |
| transmission speed |
10/100/1000 Mbps (100 Mbps(LAN 3.1 and LAN 3.2),1000 Mbps(LAN 1, LAN 2)) |
