Phoenix TRIO-PS-2G/3AC/24DC/10-power supply 2903154, using in-line connection TRIO POWER switching power supply, suitable for DIN rail installation, three-phase input, output: 24V DC/10 A
AC operation
Network Type
star network
Rated input voltage range
3x 400V AC ... 500V AC
2x 400V AC ... 500V AC
Input Voltage Range
3x 400V AC ... 500V AC -20 % ... +15%
2x 400V AC ... 500V AC -10 % ... +15%
AC input voltage range
3x 320V AC ... 575V AC
National Grid Typical Voltage
3x 400V AC
3x 480V AC
Supply Voltage
AC
Impulse current
≤ 26 A (typical)
impulse current integral (I2t)
≤ 0.3 A2s
AC frequency range
50Hz ... 60Hz
grid buffer time
Typical 10 ms (400V AC)
Typical 20 ms (500V AC)
power consumption
3x 0.6 A (400V AC)
3x 0.6 A (500V AC)
2x 1.1 A (400V AC)
2x 1.1 A (500V AC)
Rated power consumption
451.7 VA
protection circuit
transient surge protection; varistor
power factor (cos phi)
0.58
Typical Response Time
< 1 s
input fuse
3.15 A (built-in (device protection) slow fuse)
recommend use
6 A ... 16 A (characteristics B, C, D, K)
PE discharge current
< 3.5 mA
< (550V AC, 60 Hz)
efficiency
> 92% (at 400V AC and rated)
output characteristics
U/ I with dynamic load reserve
Rated output voltage
24V DC ±1%
output voltage (USet) setting range
24V DC ... 28V DC (> 24V DC, stable capacity limit)
