Phoenix OPT-60DC/ 48DC/100-Micro solid state relay 2966621, plug-in micro solid state relay, input solid state relay, 1 normally open contact, input: 60V DC, output: 3 - 48V DC/100 mA
| Product Type |
Single-phase solid state relay |
| Mode of operation |
100% operating factor |
| Insulation Characteristics: Standards/Regulations |
| insulation |
Foundation Isolation |
| Overvoltage Category |
III |
| pollution level |
2 |
| Data Management Status |
| Last data maintenance date |
19.03.2025 |
| rated conditions |
0.18W |
| test voltage (input/output) |
2.5 kV (50Hz,1 minute, input/output) |
| Rated input voltage UN |
60V DC |
| relative to UNinput voltage range |
0.9 ... 1.1 |
| Input Voltage Range |
54V DC ... 66V DC |
| switch threshold "0" signal, reference UN |
0.4 |
| switch threshold "1" signal, reference UN |
0.9 |
| UN |
3 mA |
| Typical Response Time |
50 µs (UN) |
| Typical closing time |
800 µs (UN) |
| sending frequency |
100Hz |
| Contact Type |
1 N/O contact |
| Digital Output Design |
electronic |
| Output Voltage Range |
3V DC ... 48V DC |
| limit continuous current |
100 mA |
| Voltage drop at maximum limited continuous current |
≤ 1V |
| output circuit |
2-wire connection, floating |
| protection circuit |
polarity protection; polarity protection diode |
| Surge Protection |
| width |
5mm |
| height |
28mm |
| depth |
15mm |
| environmental conditions |
| protection level |
RT III |
| ambient temperature (operation) |
-25°C ... 60°C |
| ambient temperature (storage/transport) |
-25°C ... 70°C |
| Corrosive gas test |
| identification |
ISA-S71.04. G3 Harsh Group |
| EN 60068-2-60 |
| Standards/Regulations |
| Standards/Regulations |
IEC 60664 |
| EN 50178 |
| Assembly Instructions |
no spacing arrangement |
| Installation position |
arbitrary |
